CARTONING MACHINE FOR BLISTER PACKS
Model No.CHS120
With intermittent structure, it's built with 3-axis servo control system with easy set up and maintenance. Average speed 60 BPM.
| SPEED | 60 BPM |
| BOX SIZE | 70~180 (L) x 60~120 (W) x 30~100 (H) (m/m) |
| AIR PRESSURE | 5 (Kg/cm²) |
| POWER SUPPLY | 3Ø 220V 50/60HZ 5.5KW |
| MACHINE SIZE | 2800 (L) x 1050 (W) x 1725 (H) (m/m) |
12 / 12
Cartoner Super High Speed (Horizontally insert contents)
Model No.CHC120
A cartoner that's driven by one motor for all mechanisms. It is designed to enhance PTP production to reach speed up to 300 box per minute.
| SPEED | Max. 300 BPM |
| BOX SIZE | 35 ~ 100 (L) x 20 ~ 80 (W) x 20~80 (H) (m/m) |
| AIR PRESSURE | 5 (Kg/cm²) |
| POWER SUPPLY | 3Ø 220V 50/60HZ 5.5KW |
| MACHINE SIZE | 4420 (L) x 1530 (W) x 1510 (H) (m/m) |
